13
Step Remarks
Installing accessories to
the chassis
Accessories to be installed on the chassis:
• For how to mount brackets and cable management brackets, see “Installing
mounting brackets and cable management brackets.”
• For how install an air filter (optional), see “Installing an air filter.”
Mounting the switch to
the rack
—
Connecting the PGND
cable
—
Inspecting the switch
Follow these steps before installing an H3C S7500E switch:
• Make sure that you have read the chapter “Preparing for installation” carefully and the installation
site meets all the requirements.
• Make sure a 19-inch rack is ready for use. For how to install a rack, see the rack installation guide.
• Make sure that the rack is sturdy and securely grounded; the installation position on the rack is
appropriate for the chassis; no debris exists inside or around the rack.
• Make sure the switch is ready for installation and has been carried to a place near the rack and
convenient for moving.
IMPORTANT:
To ensure the stability of the rack, mount the switch at the lowest possible position. To mount multiple
switches on the rack, mount the heaviest switch at the bottom of the rack.
Installing slide rails and cage nuts to the rack
Installing slide rails
Before installing the switch to the rack, install slide rails to the rack. If the rack has slide rails, skip this
section.
NOTE:
• Before installing the slide rails, check that the slide rails can support the weight of the switch. For the
weights of the S7500E series, see the chapter “Appendix A Hardware specifications.”
• For the slide rails, H3C recommends that you order the H3C Slide Rail Accessories,500mm-800mm
(LSTM2KSGD0).
• Position the chassis of the S7500E series accordin
