H3C S7500E Series Installation Manual

113
Appendix B Pluggable module ordering guide
SRPU
SRPU overview
The switching and routing processing unit (SRPU) is the core of the control management plane and the
switch fabric for the S7500E series. The S7500E series supports the following SRPU models.
NOTE:
The model of a card is LSQM-prefixed on the card package and LSQ-prefixed on the card panel. For
example, LSQ1MPUA0 and LSQM1MPUA0
identify the same card. When you order a card, you refer to
the card by its LSQM-prefixed model. In this chapter, the card models are LSQ-prefixed, the same as
marked on the card panels.
Table 37 Interfaces on SRPUs
External interfaces
SRPU model
Console
port
Management
Ethernet port
(10/100BASE-TX)
CF card
interface
Other interfaces
LSQ1MPUA0 One One One —
LSQ1CGV24PSC0 One One —
• 20 × 10/100/1000Base-T
Ethernet interfaces (RJ-45)
• 4 × combo ports
LSQ1CGP24TSC0 One One —
• 16 × Gi g ab i t / 10 0 -M b p s
SFP interfaces (LC)
• 8 × combo ports
LSQ1MPUB0
(Salience VI-Lite)
One One One —
LSQ1SRPA0
(Salience VI-Smart)
One One — —
LSQ1SRPB0
(Salience VI)
One One One —
LSQ1SRPD0
(Salience VI-Plus)
One One One —
LSQ1SRP1CB0
(Salience VI-Turbo)
One One One —
LSQ1SRP12GB0
(Salience VI-GE)
One One One
12 × Gigabit/100-Mbps SFP
interfaces (LC)
