H3C S7500E Series Installation Manual

115
Applicable chassis
(right)
SRPU model
(below)
S7502E
S7503E-
S
S7503E
S7506E-
S
S7506E S7510E
S7506E-
V
LSQ1SRP1CB0
(Salience VI-Turbo)
— —
z
—
z z z
LSQ1SRP12GB0
(Salience VI-GE)
— —
z
—
z z z
LSQ1SRP2XB0
(Salience VI-10GE)
— —
z
—
z z z
LPU
LPU overview
The S7500E series supports various LPUs. The number and type of interfaces provided by an LPU depend
on the LPU type.
NOTE:
The model of a card is LSQM-prefixed on the card package and LSQ-prefixed on the card panel. For
example, LSQ1FP48SA0 and LSQM1FP48SA0 identify the same card. When you order a card, you refer
to the card by its LSQM-prefixed model. In this chapter, the card models are LSQ-prefixed, the same as
marked on the card panels.
Table 39 LPU specifications
LPU Description
Conne
ctor
Number
of
interfaces
Interface
transmission rate
Available
transceiver
modules
LSQ1FP48
SA0
48-port 100-Mbps optical
Ethernet interface card (SFP,
LC)
LC 48 100 Mbps
100-Mbps SFP
module
LSQ2FP48
SA0
48-port 100-Mbps optical
Ethernet interface card (SFP,
LC)
LC 48 100 Mbps
100-Mbps SFP
module
LSQ2FT48
SA0
48-port 100-Mbps electrical
Ethernet interface card
(RJ-45)
RJ-45 48
10/100 Mbps,
half/full-duplex
—
LSQ1FV48
SA0
48-port 100-Mbps electrical
Ethernet interface card
(RJ-45)-PoE
RJ-45 48
10/100 Mbps,
half/full-duplex
—
