123
Air filter
Air filter overview
To prevent dusts from entering the chassis, you can configure air filters for the switch as needed and
install the air filters at the air intakes.
CAUTION:
Clean air filters periodically (at least once every three months) to guarantee adequate ventilation and
avoid over-temperature.
Air filter ordering guide
Different S7500E switches support different air filters. Order air filters compatible with your switch.
PoE DIMM
PoE DIMM overview
The S7500E series switch support various PoE LPUs.
• To supply power through PoE, you must install a PoE dual-in-line memory (DIMM) module on the PoE
LPU and implement the PoE function on the LPU.
• When a PoE LPU is not installed with a compatible PoE DIMM module, the Ethernet ports on the LPU
cannot supply power through PoE, and are common Ethernet ports.
PoE DIMM ordering guide
NOTE:
The model of a card is LSQM-prefixed on the card package and LSQ-prefixed on the card panel. For
example, LSQ1GV48SD0 and LSQM1GV48SD0 identify the same card. When you order a card, you
refer to the card by its LSQM-prefixed model. In this chapter, the card models are LSQ-prefixed, the same
as marked on the card panels.
Table 43 PoE DIMM module and PoE LPU compatibility matrix
PoE LPU
Number of
PoE-capable
ports
Compatible PoE DIMM module
PoE powering
type
LSQ1GV48SD0 48
No PoE DIMM is needed for supplying power
through PoE
Type 1, Type 2
LSQ1CGV24PSC0
