6 - Maintenance
172
Gasket Types
Usually an O-ring is used, but there is also a different type of gasket in
use (F).
How To Remove Lock Ring
If the lock ring needs to be replaced, this can be done by mounting a
connector (A) in reverse direction.
• Push the connector over the lock ring.
• Place the connector right behind the lock ring and pull to remove
the lock ring from the pipe.
BoomPrime One-Way Valve
If the one-way valves for the BoomPrime system are clogged, they must
be cleaned.
1. Disassemble the two parts.
2. Clean the parts as needed. Check the state of the black O-ring.
3. Assemble the parts again and tighten with a torque of 1 Nm.
4. ATTENTION! If any part is worn or damaged, it should be replaced.
