6 - Maintenance
145
÷
The excess of coolant is automatically eliminated through the outlet pipe
μ
ATTENTION! Only use the recommended coolant. Never mix with other coolants. If in doubt, drain the cooling circuit
completely.
Engine Suction System
μ
Do not work when the engine is running!
÷
Pay attention to utmost cleanliness when working on the intake system, close intake openings if necessary. Dispose
of old filter elements properly.
Dry air filter
±
Do not clean the filter element (1) with petrol or hot liquids!
Renew damaged filter elements.
• Lift up the clamping yoke.
• Remove the filter hood and pull out the filter element
• Filter element
- blow out with dry compressed air (max. 5 bar) from the inside if
soiling is only slight
- renew if heavily soiled
Renewing the safety cartridge of the dry air filter
• Renew safety cartridge according to the interval in the maintenance schedule
• To do this:
- Unscrew hexagon nut, pull out safety cartridge
- Insert new safety cartridge, screw on hexagonal nut
• Insert filter element, mount hood and fix with clamping yoke
Clean the dust discharge valve of the dry air filter
• Empty the dust discharge valve by pressing together the discharge
slit
• Remove any caked dust by pressing together the upper section of
the valve
• Clean the discharge slit
÷
The intervals of verification and cleaning can be reduced depending on the usage environment of the machine
÷
For more information, Refer to DEUTZ TCD 6.1 L6 manual in chapter «Suction System»
