4 - Sprayer Setup
74
Spraying
Spraying pump
• Screw the plug (1) (if necessary) in the 464 pump.
Fitting the nozzles
Install appropriate nozzles to achieve optimum spray quality
• Place the nozzle filter (1) in the nozzle nut (2)
• Fit the nozzles equipped on the nozzle holder, by turning the nut
a 1/4 turn.
CycloneFilter
Standard filter size is 80 mesh. Filters of 50 and 100 mesh are available
and can be changed by opening the filter top.
Check condition of O-rings and lubricate if necessary, or replace them if
damaged, before reassembly.
