7 - Repair
205
Lightening
Highlights
A. Replace the halogen lights bulb:
μ
ATTENTION! Before changing the bulb, make sure the unit is
turned off and wait until the lamp is completely cooled if you do
not want to burn yourself.
• Disconnect the connector (1).
• Turn the lamp holder (2) counter-clockwise.
• Replace the halogen bulb.
Halogen bulb type: H1 - 12 V - 55W.
÷
NOTE! Never touch the halogen lamp directly with the fingers, but hold it with a cloth.
B. Adjusting the projector
When you need to replace a projector, make sure it is designed
according to the direction of traffic, right for most countries, or left for
other countries(
1
)
L : Left-hand traffic.
R : Right-hand traffic
1. Traffic direction screw.
2. Light beam adjustment screw.
1. United kingdom, South Africa Australia, etc..).
