3 - Description
62
Cabin ceiling controls
Speed selector and Parking brake
1. FIELDS mode (Downhill).
2. FIELDS mode (Uphill).
3. FIELDS mode
4. AUTOMOTIVE mode (Road).
5. Parking brake.
1. 2-position windscreen wiper switch (permanent,
intermittent) switch
2. Windscreen washer switch.
3. Front working headlights switch.
4. Rear working headlights switch.
5. Boom lighting switch.
6. Hazard light switch.
7. Not used.
8. Not used
9. Not used.
10. Temperature sensor.
11. Wing mirror adjustment switch.
12. Air conditioning control unit.
13. Map light.
14. Cabin lightning.
15. 3-position ceiling light switch.
16. Map light switch.
1
2
3
4
5
6
8
9
11
10
12
15
16
13
14
7
HIHI
A/C
HILO
O
F
F
!
5
4
/
1
2
4
5
3
