6 - Maintenance
148
AdBlue Filter Replacement
±
Protective gloves are to be worn when working with Selective Catalytic Reduction (SCR) components. Ensure
cleanliness.
Servicing
• Switch off the engine.
• Electrical connection
– Disconnect cable connections.
• Place suitable collecting containers underneath.
• Remove cover (1).
Socket wrench insert 27 mm
• Pull out filter insert and compensation body (2).
• Insert new filter (3) insert with compensation body.
• Mount cover.
Tightening torque 22.5 ±2.5 Nm
• Electrical connection
– Connect cable connections.
• Start
Filter Cartridge Part Number: 27065001
÷
For more information, refer to DEUTZ TCD 6.1 L6 manual instruction in chapter «SCR»
Cooling System
Specifications when working on the cooling system
±
Danger of scalding from hot coolant! Cooling system under pressure!
Only open the cap when cool! The coolant must have a prescribed concentration of cooling system corrosion
protection agent!
Observe safety regulations and national specifications when handling cooling media.
Dispose of leaking liquids properly and do not allow them to seep into the ground.
Never operate the engine without coolant, even for a short time!
Emptying the coolant system
• Open cooler locking cap (1) carefully.
• Place suitable collecting containers underneath
• Remove screw (2) in the radiator and screw (3) if it is accessible
• Drain coolant.
• Insert screw again with sealant
Filling and bleeding coolant circuit
• Open the cooling system cap (1) carefully.
• Fill coolant up the expansion tank to the filling limit.
• Switch on any available heating and set to the highest level so that the heating circuit is filled and vented.
• Close cooler locking cap.
