6 - Maintenance
160
4. Place the filter/filter lid into the housing and screw the lid, until it hits the stop.
±
WARNING! Always wear protective clothing and gloves, before servicing the filter!
€
DANGER! Both the suction valve andThe pressure SmartVvalve must always be closed turned to the unused function
or to “tank cleaning nozzles”, before opening the CycloneFilter! If not, the spraying liquid can hit you, when opening
the filter, and the main tank content will drain away!
In-Line Filter
If PrimeFlow is equipped with In-Line-Filter in the spray boom, these
filters a not included
If the boom is equipped with In-Line Filters, unscrew the filter bowl to
inspect and clean the filter. When reassembling, the O-ring should be
greased.
Alternative filter meshes are available. See section “Technical
specifications” - Filters and nozzles.
±
WARNING! Be careful not to splash out liquid, when unscrewing
the filter bowl.
±
WARNING! Always wear protective clothing and gloves, before
servicing the filter!
Nozzle Filter
The filters are located in the nozzle holder.
Check the filter condition and clean the filter.
Spraying circuit
Fill with clean water and operate all functions
Check for leaks using a higher spray pressure than normal.
Check nozzle spray patterns visually using clean water
Greasing the pump
When operating the pump, it must be greased every 50 hours with 30
grams of grease into each lubrication point.
μ
ATTENTION! In order to avoid excessive wear, it is important to
use a recommended lubricant! See the section “Recommended
Lubricants” for more information.
μ
ATTENTION! The pump MUST be stopped during greasing!
