4 - Sprayer Setup
76
Chassis
Altering the track width
(*) mini track width is 2.00 m in ground clearance 1.65 m
Track width (m) for ground clearance 1.20 m
300/95R52 340/85R48 380/90R46 420/80/ R46
480/80R42
480/80R46
520/85R38
520/85R42
650/65R38
Rim offset +125 +100 +90 +60 +15 -15 -30
Axle typeminmaxminmaxminmaxminmaxminmaxminmaxminmax
S NA NA NA NA 1.76 2.00 1.82 2.05 1.91 2.14 1.97 2.20 2.06 2.29
M 1.90 2.23 1.94 2.29 1.95 2.31 2.02 2.37 2.10 2.46 2.16 2.52 2.25 2.61
L 2.12 2.63 2.18 2.69 2.19 2.71 2.25 2.76 2.34 2.85 2.40 2.91 2.49 3.00
XL 2.53 3.05 2.59 3.10 2.60 3.12 2.66 3.17 2.75 3.26 2.81 3.32 2.90 3.41
XXL 2.78 3.30 2.84 3.35 2.85 3.37 2.91 3.42 3.00 3.51 3.06 3.57 3.15 3.66
Track width (m) for ground clearance 1.65 m
300/95R52 340/85R48 380/90R46 420/80/ R46
480/80R42
480/80R46
520/85R38
520/85R42
650/65R38
Rim offset +125 +100 +90 +60 +15 -15 -30
Axle typeminmaxminmaxminmaxminmaxminmaxminmaxminmax
M 1.97 2.33 2.02 2.38 2.04 2.40 2.10 2.46 2.20 2.55 2.25 2.61 2.28 2.64
L 2.21 2.72 2.26 2.78 2.28 2.79 2.34 2.85 2.34 2.95 2.49 3.01 2.52 3.04
XL 2.62 3.13 2.67 3.19 2.69 3.20 2.75 3.26 2.85 3.36 2.90 3.42 2.93 3.45
HTA axle Track wt width (m) for ground clearance 1.20 m
300/95 R52 IF 320/90 R50
VF 380/90 R46
VF 380/90 R50
420/80 R46 480/80/ R42 520/85 R42 650/65 R38
Rim offset +125 +100 +90 +60 +15 -15 -30
Axle type min max min max min max min max min max min max min max
HTA - S 1.75 2.75 1.80 2.80 1.82 2.82 1.88 2.88 1.97 2.97 2.03 3.03 2.06 3.06
HTA - M 2.02 3.12 2.07 3.17 2.09 3.19 2.15 3.25 2.24 3.34 2.30 3.40 2.33 3.43
HTA axle Track width (m) for ground clearance 1.65 m
300/95 R52 IF 320/90 R50
VF 380/90 R46
VF 380/90 R50
420/80 R46 480/80/ R42 520/85 R42 650/65 R38
Rim offset +125 +100 +90 +60 +15 -15 -30
Axle type min max min max min max min max min max min max min max
HTA - S 1.85 2.85 1.90 2.90 1.92 2.92 1.98 2.98 2.07 3.07 2.13 3.13 2.16 3.16
HTA - M 2.12 3.22 2.17 3.27 2.19 3.29 2.25 3.35 2.34 3.44 2.40 3.50 2.43 3.53
