Disk Drive Status LEDs
Refer to Figure 8–38 and Table 8–37 for information on the Disk Drive Status LEDs. Refer to the
Harmonic MediaGrid Component Replacement Guide for instructions on replacing a failed drive.
Figure 8–38: Disk Drive Status LEDs
4 Heartbeat Flashing Indicates that power is being supplied to
the
server board
5 SAS-In Solid Indicates that the SAS input port is
connected.
6 Overheat/ Fan Fail Flashing Indicates fan failure
Solid
Overheat condition, which may be caused
by cables obstructing the airflow in the
system or the ambient room temperature
being too warm. Check the routing of the
cables and make sure all fans are present
and operating normally. You should also
check to make sure that the chassis covers
are installed. Finally, verify that the heats
inks are installed properly
Symbol LED Color/State Description
0
OPEN
LEDs
