User Manual
Operation and Management
Page 4-10 (Rev. 4.1/ SW v1.60/ December 2006)
FREQUENCY RANGE
The Frequency Range parameter defines the input frequency in the Ku, C or L
bands.
This parameter affects the displayed frequencies and ranges of the PVR 6000
DVB-S receiver parameters.
Frequency Range
1 L BAND
2{ Ku BAND
3{ C BAND
The available options are:
• L-BAND – Receiving in the L-Band frequency range
• Ku-BAND – Receiving in the Ku-Band frequency range
• C-BAND – Receiving in the C-Band frequency range
FREQUENCY BAND SCAN
The Frequency Band Scan command allows scanning the selected frequency
range if the frequency is unknown. The symbol rate must be known and set in
the IRD. The PVR 6000 scans the frequency range, while seeking a valid DVB
stream. Upon locating a valid DVB stream, the PVR 6000 marks the located
frequency and service name. Results output either to the RS-232 port (terminal)
or Telnet. The following screen displays the Frequency Band Scan Screen
NOTE
The PVR 6000 scans only the L-band frequency range. Located frequencies are
shown in L-Band and must be modified for the relevant frequency value if they
are tuned to either C-band or Ku-band.
Frequency Band Scan
1 OFF
2{ ON
The available options are:
• OFF – Frequency scan is disabled
• ON – Frequency scan is enabled
