PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-17
LNB 22KHZ
The LNB-22KHz menu enables selecting between LNB low band and high band
reception, by generating a 22 kHz signal that is sent to the LNB for this purpose.
LNB 22KHz
1 OFF (Low Band)
2{ ON (High Band)
The available options are:
• OFF (Low Band) – the 22 kHz signal is not generated, and low band
reception is selected
• ON (High Band) - the 22 kHz signal is generated and high band reception
is selected.
INPUT SIGNAL SOURCE
The Input Signal Source menu selects the RF interface source through which
to acquire the signal to be received. This menu exists only in Dual RF Input PVR
6000 devices.
Input Signal Source
1 IN-A
2{ IN-B
The available options are:
• IN-A – the PVR 6000 receives the input signal from RF IN 1 interface
• IN-B - the PVR 6000 receives the input signal from RF IN 2 interface
