GigE Area Scan Camera User Manual
100
Note
After setting user parameters, it is recommended to save user parameters and select them
as the default parameters.
12.9.1 Save User Set
Steps
1. Go to User Set Control, and select a user set in User Set Selector.
Note
Here we take selecting User Set 1 as an example.
2. Click Execute in User Set Save to save parameter.
3. View User Set Save Status:
●
Saving: User parameters are being saved.
●
Ready: User parameters have been saved.
Figure 12-18 Save User Set
12.9.2 Load User Set
Note
Loading user set is available only when the device is connected but without live view.
Steps
1. Go to User Set Control, and select a user set in User Set Selector.
Note
Here we take selecting User Set 1 as an example.
2. Click Execute in User Set Load to load parameter.
3. View User Set Load Status:
To Next Page
