Chapter 4 Installation
4.1 Installation Preparation
You need to prepare following accessories before device installation.
Table 4-1 Accessories
No.
Name
Quantity
Description
1
Power and I/O
Cable
1
It refers to the 6-pin or 12-pin power and I/O cable.
You need to purchase separately.
2
DC Power Supply
1
You should select suitable power adapter or switch
power supply according to the device power supply
and consumption. You need to purchase separately.
3
Network Cable
1
It refers to CAT-5e network cable or above. You need
to purchase separately.
4
Lens
1
It refers to the lens that is suitable for the device. You
need to purchase separately.
5
Lens Adapter
1
If the lens you used does not match with lens mount
of the device, you need to use a lens adapter. You
need to purchase separately.
4.2 Install Device
Before You Start
● Make sure that the device in package is in good condition and all assembly parts are
included.
● Make sure that all related devices are powered off during the installation.
Steps
1. Fix the device to the installation position.
2. Install the lens to the device.
3. Use a proper network cable to connect device with a GigE switch or a network interface
card.
4. Select a power supply method:
● Direct power supply: Use the 6-pin or 12-pin power and I/O cable to connect device to a
proper power adapter.
● PoE (Power over Ethernet): For the device that supports PoE, use a network cable to
connect the device to a switch that supports PoE or a network interface card.
