B 5231 / H51q-MS (0605)
100
4 Wiring of the assembly kit
The assembly kit is already wired for operation. Wirings have still to be done by the user (op-
tional modules, see "Assembly kit, wiring diagram").
4.1 Current distribution within the assembly kit
4.1.1 HIMA devices for current distribution
It is recommended to use the HIMA supplies and current distributions:
4.1.2 Supply 24 VDC
The 24 VDC power supply can be feeded three times to the system H51q-MS (starlike wiring).
See also catalog H41q/H51q, chapter 4.3, The Input/Output Level, 24 VDC Supply and Distri-
bution.
4.1.3 Output 24 VDC
With installation of the assembly kit a conductive connection to the
frame or a separate earth connection has to be installed according to
the EMC requirements. Connection PE earth: Faston 6.3 x 0.8 mm.
Pay attention for the manufacturers information concerning detaching
and replugging of the Faston connectors!
K 7212 redundant feeding up to 35 A total current, with 2 decoupling diodes and 2 net-
work filters, with fusing of up to 12 single circuits with circuit breakers or
K 7213 redundant feeding up to 35 A total current, with fusing of up to 12 single cir-
cuits with circuit breakers or
K 7214 redundant feeding up to 150 A total current, with fusing of up to 18 single cir-
cuits with circuit breakers or
K 7215 redundant feeding up to 150 A total current, with fusing of up to 18 single cir-
cuits with circuit breakers, graphical display.
Connection Wire and connection Fusing Use
XG.21/22/23:2 (L+)
RD 2.5 mm
2
, Faston 6.3 x 0.8
max. 16 A gL PS1...PS3
XG.21/22/23:1 (L-)
BK 2.5 mm
2
, Faston 6.3 x 0.8
Reference pole L-
RD = Color code red BK = Color code black
Table 1: Supply 24 VDC
Connection Wire and connection Use
XG.24:2 (L+)
RD 1.5 mm
2
, Faston 6.3 x 0.8
Supply fuse monitoring and IO-CON in
the I/O rack
RD = Color code red
Table 2: Output 24 VDC
