HIMA H41q User Manual

BV 7048 (0508)
All rights reserved. Equipment subject to change without notice: 163
HIMA Paul Hildebrandt GmbH + Co KG, P.O. Box 1261, 68777 Brühl
BV 7048
BV 7048: Data connecting cable
Connection of the interface converter H 7505 to the interface in
the redundant H41q/H51q systems
Standard length: 4 m, bigger lengths on request
Figure 1: Wiring
Type of used cable: LifYCY 3 x 2 x 0.08 mm
2
2
R1 R3
2
3
4
R4
R2
3
4
5
8
9
R6R5
5
8
9
3
4
5
8
9
WH
GN
GY
BN
YE
PK
390 Ω
390 Ω
150 Ω
150 Ω
390 Ω
390 Ω
GN
GY
BN
YE
PK
Screen
X1
MIN-D plug,
9-pole
CPU
X3
MIN-D plug,
9-pole
CPU
X2
MIN-D plug,
9-pole
H 7505
91
919
1
HIMA
BV7048-XX
X1
X2 X3
00. wwwwww.xxx
gepr.
H 7505 Central
module
Central
module
l = 4 m
l = 0.3 m
