6.2 Mechanical Conditions
The most important tests and limit values for mechanical conditions are listed in the following
table:
6.3 EMC Conditions
The most important tests and limit values for EMC conditions are listed in the following tables:
All modules of the systems H41q and H51q meet the requirements of the EMC directive of the
European Union and have the CE sign.
With interferences exceeding the limits mentioned above all the systems have a safety-related
reaction.
IEC/EN 61131-2
Chapter 6.3.5
Mechanical Tests
Vibration test, operating: 5...9 Hz / 3.5 mm
9...150 Hz / 1 g
6.3.5.1 Immunity vibration test:
10...150 Hz, 1 g, EUT operating, 10 cycles per axis
6.3.5.2 Immunity shock test:
15 g, 11 ms, EUT operating, 2 cycles per axis
IEC/EN 61131-2
Chapter 6.3.6.2
Noise Immunity Tests
6.3.6.2.1
IEC/EN 61000-4-2
ESD test: 4 kV contact / 8 kV air discharge
6.3.6.2.2
IEC/EN 61000-4-3
RFI test (10 V/m): 26 MHz...1 GHz, 80 % AM
6.3.6.2.3
IEC/EN 61000-4-4
Burst test: 2 kV power supply / 1 kV signal lines
6.3.6.2.4
IEC/EN 61000-4-12
Damped oscillatory wave immunity test: 1 kV
IEC/EN 61000-6-2 Noise Immunity Tests
IEC/EN 61000-4-6 Radio frequency common mode:
10 V, 150 kHz...80 MHz, AM
IEC/EN 61000-4-3 900 MHz pulses
IEC/EN 61000-4-5 Surge: 1 kV, 0.5 kV
IEC/EN 61000-6-4 Noise Emission Tests
EN 50011
Class A
Emission test:
radiated, conducted
