3 The H41q System Family
The H41q system family comprises compact designed PES in single channel and redundant
models, also with TÃœV safety certificate.
All input/output modules can be used with both redundant and single channel models of the
central modules.
All modules of the H41q system family meet the requirements for electromagnetic compatibility
and immunity according to article 10 of the EG guideline 89/336/EWG for the electromagnetic
conformity. This is demonstrated with the CE sign within the data sheets of the modules. Also
the systems and modules are wearing a label with this sign.
All models of the H41q system family have all the components required for control tasks in one
19 inches subrack, 5 units high, with an integrated cable tray (see also data sheets of H41q
systems or assembly kits).
3.1 Overview Assembly Kits H41q
The components required for a working system are included in assembly kits:
* Options
Abbreviations: CM Coprocessor Module
CoM Communication Module
CU Central Module
I/O Input/Output
System H41q-M H41q-H H41q-HR H41q-MS H41q-HS
H41q-
HRS
Safety – – – SIL 3 SIL 3 SIL 3
Quantity/type
CU
1 x
F 8653X
2 x
F 8653X
2 x
F 8653X
1 x
F 8652X
2 x
F 8652X
2 x
F 8652X
Quantity/type
CM *
1 x
F 8621A
(2 x) 1 x
F 8621A
(2 x) 1 x
F 8621A
1 x
F 8621A
(2 x) 1 x
F 8621A
(2 x) 1 x
F 8621A
Quantity/type
CoM
(Fast Ethernet) *
1 x
F 8627/
F 8627X
(2 x) 1 x
F 8627/
F 8627X
(2 x) 1 x
F 8627/
F 8627X
1 x
F 8627/
F 8627X
(2 x) 1 x
F 8627/
F 8627X
(2 x) 1 x
F 8627/
F 8627X
Quantity/type
CoM
(Profibus-DP) *
1 x
F 8628/
F 8628X
(2 x) 1 x
F 8628/
F 8628X
(2 x) 1 x
F 8628/
F 8628X
1 x
F 8628/
F 8628X
(2 x) 1 x
F 8628/
F 8628X
(2 x) 1 x
F 8628/
F 8628X
Quantity/type
power supply
1 x
F 7130A
2 x
F 7130A
2 x
F 7130A
2 x
F 7130A
2 x
F 7130A
2 x
F 7130A
Quantity
I/O buses
112112
max. quantity
I/O modules
13 13 7 + 6 13 13 7 + 6
Assembly kit
number
B 4234 B 4236-1 B 4236-2 B 4235 B 4237-1 B 4237-2
Table 2: Overview Assembly Kits H41q
