H 7020 (0606)
All rights reserved. Equipment ssubject to change without notice: 493
HIMA Paul Hildebrandt GmbH + Co KG, P.O. Box 1261, D-68777 Brühl
H 7020
H 7020: Terminal Module
• For connection between the I/O modules and the field level
• For DIN-Rail mounting
Figure 1: Block Diagram
Technical Data
Permissible voltage max. 48 VDC, 30 VAC SELV or PELV
Current per channel X1...X16 2 A
X21...X22 4 A
Total current (X1-X16) max. 16 A
Cross section A, B, C 0.2...1.5 mm
2
(Combicon Connector)
D, F 0.2...1.5 mm
2
Ambient temperature range -20°C to +50°C
Dimension (L x W x H) 90 mm x 91.5 mm x 60 mm
Mounting on 35 mm DIN-Rail
Weight ca. 130 g
Installation orientation horizontally or vertically, installation clearance
is not necessary
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
soldering points
(Lötpunkte)
X17 X18
X19
X20
X1 X2
X3
X4 X5 X6 X7 X8 X9 X10 X11 X12 X13 X14 X15 X16
X21 X22
X23
X25
X27
X24
X26
X28
A
B
C
1 : Front (vorne)
2 : Rear (hinten)
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
E
D
F
