HIMA H41q - BV 7052: Data Connecting Cable

BV 7052 (0508)
All rights reserved. Equipment subject to change without notice: 171
HIMA Paul Hildebrandt GmbH + Co KG, P.O. Box 1261, 68777 Brühl
BV 7052
BV 7052: Data connecting cable
Connection of the interface connector H 7505 to the interfaces in the single-channel HIMA PES
Standard lengths: 2 m, 4 m, bigger lengths on request
Figure 1: Wiring
Type of used cable: LifYCY 3 x 2 x 0.08 mm
2
3
4
5
8
9
2
R3R1
R5 R6
R4
R2
3
4
5
8
9
2
Sc
r
ee
n
GN
WH
GY
BN
YE
PK
390R390R
390R 390R
150R
150R
X1
MIN-D plug,
9-pole
X2
MIN-D plug,
9-pole
91
9
1
HIMA
BV7052-XX
X2 X1
00.wwwwww.xxx
gepr.
H 7505 System
