HIMA H41q User Manual

Data Sheets
51
10.13.4 Symbols in the Data Sheet Diagrams
Function unit and signal converter
Function unit and signal converter with galvanic isolation
Function unit and signal converter with safe isolation
Trigger stage (threshold input)
Amplifier in direction of signal flow
DC/DC converter
Transmitter
Analog/Digital converter
Digital/Analog converter
Automatic testing for operation
Signal contraction
Channel numbers according to "Modify Cabinet“ in ELOP II
Module with automatical test functions
Threshold input for line break and line short-circuit monitoring
I
E
=
=
#
#
T
