HIMA H41q - BV 7050: Data Connecting Cable

BV 7050 (0508)
All rights reserved. Equipment subject to change without notice: 167
HIMA Paul Hildebrandt GmbH + Co KG, P.O. Box 1261, 68777 Brühl
BV 7050
BV 7050: Data connecting cable
Connection of interfaces in the single-channel HIMA PES
H 7505 inclusive to optical fibre (FO)
or HIMA PES to PC 485 PCI interface card
Standard length: 0.5 m, 4 m, bigger lengths on request
Figure 1: Wiring
Type of used cable: LifYCY 3 x 2 x 0.08 mm
2
3
6
R4
R7
R4
R3
3
2
8
5
R5R5
8
5
150R
390R
S
creen
150R
390R
390R390R
GN
BN
YE
HIMA
X1
MIN-D plug, 9-pole
PC 485 PCI
or FO
X2
MIN-D plug,
9-pole
91
9
1
HIMA
BV7050-XX
Lütze
LWL
X2 X1
00.wwwwww.xxx
gepr.
