7 Application Notes
7.1 Configuration Notes
7.1.1 Programming System ELOP II and Operating System
For programming and operation of the H41q/H51q PES the version ≥ 3.0 of ELOP II is re-
quired.
Required operating system:
≥ BS 41q/51q V 7.0-8.
7.1.2 Cabinet Engineering
In ELOP II: After RT declaration (RT = resource type), the cabinet can be configured within the
resource.
7.1.3 Usable Function Blocks
All standard function blocks of HIMA are included in the operating system. Therefore the user
program only contains the call of the function block and not the code itself.
For information to the current status of the function blocks refer to the most recent state of the
ELOP II online help.
7.2 System Extensions
If an existing H51 system is changed in an H51q system and I/O racks out of the assembly kit
B 9301 are still part of the system it could be extended always with I/O racks out of the assem-
bly kit B 9302. These extensions are covered through the TÃœV certificate. The control in oper-
ation is protected for continued existence also after the end of the certificate.
7.3 Installation of the Output Modules of the H50 Family
The following modules may only be installed in the I/O subrack B 9301 assembly kit: F 3311,
F 3312, F 3313, F 3314, F 3321, F 3323, F 3412, F 3413, F 6701. There are many specialties
(watchdog shutdown etc.) with installation in the I/O subrack B 9302, so it is urgently advised
against the use of this kit with these modules. The faultless operation of the modules in B 9302
kit is not guaranteed.
The TÃœV certificate of the testable, SIL 3 modules (F 3313, F 3314
and F 3323) is expired cause of changing of the corresponding stan-
dard.
Therefore an application for new plants is not admissible.
Because of the new designed realization of the shutdown in the
B 9302 assembly kit the supply voltage of an old output module can
not be switched off automatically in case of a defective central module
and so the outputs of the corresponding module can not be reset inde-
pendent from the CPU.
