HIMA H41q User Manual

F 5220 (0625)
All rights reserved. Equipment subject to change without notice: 265
HIMA Paul Hildebrandt GmbH + Co KG, P.O. Box 1261, 68777 Brühl
F 5220
F 5220: 2-channel counter module
safety-related, applicable up to SIL 3 according to IEC 61508
• for input signals 24 V and 5 V, safety-related proximity switches and
proximity switches according to DIN EN 60947-5-6
• Counting range 0 Hz to 1 MHz, for pulse counting, gate time monitoring via adjustable
gate time, with recognition of rotation direction
• Fast switching output independent from the PES cycle time
The module records fast pulses for use in HIMA PES.
Figure 1: Block diagram and front cable plug
Appertaining function block: HF-CNT-3
Pulse input
• 1-signal 5 VDC (switching level high: 3 V), 6 mA
24 VDC, max. 8 mA
• Counting frequency max. 1 MHz (5 VDC)
• Edge steepness min. 1 V/µs
Proximity switch input
• Counting frequency max. 50 kHz
2
Direction Output
Counter
21
211
Z 7152 / 5220
01 02
d12 d16
z12 z16
Decoder
μ
μ
μ
P1
P3
P2
I/O bus
II
II
EE
EE
+24V +24V
+5V +5V
z4 z26 z32 z18 z2 z20 d6 d8 d2 d4 d10 d14
d22 d26 z22 d20
X10
z16
d24 d28
d24 d28
z10 z14 z6 z8
or
<12W
Output
power
<12W
Output
power
+8,2 V
L-
L-
L+
L+
=
=
F5220
+
5
V
G
ND
Z6 d6 z30 d30
L-
L-
d26
X14
L- d22 L- d26 d22 X16 d16 z12 X12 d12
z24 d18 d30 d32 z28 z30
Direction CounterOutput
L- d24 L- d28
Front
cable plug
