F 5203 (0507)
264
With 1-signal at the zero setting input (NS) the 14 bit ring counter is set on zero and the value
32,768 is transferred to the digital output. 0-signal transfers 0 to the digital output.
Counting mode
UM = 1-signal
ZE = counting pulses
The counting direction depends on a binary signal at the input RE:
0-signal = forward,
1-signal = backward.
Discriminator mode
UM = 0-signal
ZE = counting pulses
The counting direction depends on the signal sequence of the inputs RE and ZE.
If the signal on ZE changes before RE the counting direction is forward.
If the signal on ZE changes after RE the counting direction is backward.
Figure 2: Lead marking of the cable plug Z 7127 / 5203 / C..
Function Connection Color
ZE
RE
UM
NS
none
none
none
none
d2
d6
d10
d14
d18
d22
d26
d30
WH
BN
GN
YE
GY
PK
BU
RD
L- z2 (L-) BK
Lead marking of the cable
plug Z 7127 / 5203 / C..
Cable
LiYY 8 x 0.5 mm
2
Flat pin plug
2.8 x 0.8 mm
2
q = 1 mm
2
l = 750 mm
