HIMA H41q User Manual

F 3221 (0524)
182
Lead marking of the cable plug
Z 7116 / 3221/C..
Figure 2: Lead marking of the cable plug
Figure 3: Test plug construction Z 7201 / 3221 + 25
Channel Connection Color
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
d2
d4
d6
d8
d10
d12
d14
d16
d18
d20
d22
d24
d26
d28
d30
d32
WH
BN
GN
YE
GY
PK
BU
RD
BK
VT
WHBN
WHGN
WHYE
WHGY
WHPK
WHBU
L– z2 BK
Cable
LiYY 16 x 0.25 mm
2
Flat pin
plug
2.8 x 0.8 mm
2
q = 1 mm
2
l = 750 mm
BK
RD
L+
L-
Flat pin plug
2.8 x 0.8 mm
2
Pushbutton position for 1-signal
Switch position for 1-signal
Switch position for 0-signal
q = 0.5 mm
l = 600 mm
2
