F 3237 (0622)
196
Figure 2: Lead marking cable plug Z 7108 / 3237 / .. and construction test plug Z 7204
* The connections (X4) to (X32) are only used at special cable connectors.
Redundant connection for a safety-related proximity switch
Figure 3: Redundant connection for a safety-related proximity switch
Cable plug: Z7108 / 3237 / C.. / R
HIMA order no.: 93 3237 300
Channel Connection Color
1d2
d4 (x4)*
WH
BN
2d6
d8 (x8)*
GN
YE
3d10
d12 (x12)*
GY
PK
4d14
d16 (x16)*
BU
RD
5d18
d20 (x20)*
BK
VT
6d22
d24 (x24)*
WHBN
WHGN
7d26
d28 (x28)*
WHYE
WHGY
8d30
d32 (x32)*
WHPK
WHBU
L–
L–
L+
z2
z32
z12
BK
BK
RD
Cable
LiYY 16 x 0.5 mm
2
Flat pin plug
2.8 x 0.8 mm
2
q = 1 mm
2
l = 750 mm
Construction test plug Z 7204
LIY 0.5 mm
2
l = 2 m
.
