HIMA H41q User Manual

F3325 (0622)
218
Interconnection with the F 6221 module
The F 3325 module can be interconnected with the F 6221 module in several different ways
(see data sheet of the module F 6221 for interconnection).
Single-channel interconnection of the supply module F 3325
6-channel supply module F 3325 with passive transmitter (e.g. for the channels 1 to 6 of the
F 6221 module).
Cable type: Z 7025/3325/ExCn, part number 93 3325101
Figure 2: Single-channel interconnection of the supply module F 3325
Pin allocation
Cable type: Z 7025/3325/ExCn, part number 93 3325101
Figure 3: Pin allocation Z 7025/3325/ExCn, part number 93 3325101
Transmitter
F 3325F 3325
b
2
z
2
F 3325
O1-
To supply voltage
monitoring module
Cable
LiYCY
6x2 0.2 mm
2
shielded
Channel Pin Color
O1-
O1+
z2
b2
WH
BN
O2-
O2+
z8
b8
GN
YE
O3-
O3+
z14
b14
GY
PK
O4-
O4+
z18
b18
BU
RD
O5-
O5+
z22
b22
BK
VT
O6-
O6+
z28
b28
GY-PK
RD-BU
Cable shield YEGN
