HIMA H41q User Manual

F 3334 (0626)
238
Figure 2: Lead markings of the cable plugs
Figure 3: 2-pole connection
Operating points of line monitoring
short circuit current 2.6...5 A
line break 0.5...9.5 mA
Lead marking of the cable plug
Z 7134 / 3334 / C.. / P2
2-pole connection
Chan-
nel
Connec-
tion
Color
1
2
3
4
b4
x4
b8
x8
b24
x24
b28
x28
BN
WH
YE
GN
PK
GY
RD
BU
L–
L+
z2
z12
BK
RD
Cable
LiYY 8 x
1.5 mm
2
Flat pin
plug
2.8 x
0.8 mm
2
q = 1 mm
2
l = 750 mm
Lead marking of the cable plug
Z 7134 / 3334 / C..
Chan-
nel
Connec-
tion
Color
1
2
3
4
b4
b8
b24
b28
WH
BN
GN
YE
L–
L+
z2
z12
BK
RD
Cable
LiYY 4 x
1.5 mm
2
Flat pin
plug
2.8 x
0.8 mm
2
q = 1 mm
2
l = 750 mm
