F 6221 (0625)
308
Operating data 5 V, 125 mA
24 V, 300 mA
Space requirement 4 SU
Nominal input voltage 0 to 1.00 V
Nominal input current 0 to 20.0 mA (via shunt)
Range of use of voltage -0.1 V to 1.1 V
Range of use of current -2 mA to 22 mA
R*: Shunt for current measuring 50
Ω, T < 10 ppm/K
tolerance 0.05 %
part number: 00 0710490
Resolution 1 V = 10,000 parts
20 mA = 10,000 parts
Updating interval of measuring values < 80 ms
Input resistance min. 1 M
Ω
Time constant of input filter ca. 7 ms
Converting time max.1.8 ms for one channel
Maximum error 0.1 % at 25 °C
Max. variation factor
due to temperature 0.1 % / 10 K
Max. temperature variation 0.2 % at -10 °C...+70 °C
Safety-related variation limit 1 %
Electric strength of inputs 5 V
Maximum current via shunt 80 mA
Transmitter supply voltage monitoring for channels 1 to 8
Input voltage max. 30 V
Switch-off limit < 16.0 V
Input resistance min. 30 k
Ω
Electric strength of inputs 30 V
The module must only be operated with forced ventilation (fan).
The fan (K 9203) must be installed above the subrack where the
F 6221 module is plugged in.
If the F 6221 module is operated in an H 41q, the fan (K 9212) must be
installed directly under the F 6221 module.
In order to ensure the forced ventilation, the air deflector panel M 7201
(1 HE) must to be mounted over the fan (K 9203) or over the kit H 41q.
The air deflector panel M 7201 deflects the warm air to the rear, in
order to avoid a temperature rise of the subracks and modules which
are mounted above.
Note The block diagram of F 6221 shows the wiring with the supply module
F 3325. In this wiring variant, the first six channels of the F 3325 mod-
ule are used for passive transmitters. The channels 7 and 8 are used
for active transmitters (see Variant A1 and A2).
The pins d4 and d30 on the front socket of the F 6221 are omitted
(coding of the front plug).
