F 8627X (0650)
372
Table 8: Overview of the communication with a HIMA OPC server via the F 8627X in combination
with HIPRO-S
OPC without
Passive Mode
OPC with
Passive Mode
OPC with Passive Mode +
HIPRO-S-DIRECT
F 8625 from version 1.x
F 8627 / F 8627X
from version 2.x on
F 8625 from version 1.13
F 8627 / F 8627X
from version 2.x on
F 8627 / F 8627X
from version 3.x on
DIRECT Mode Off
Switch 1/7 (OFF)
DIRECT Mode Off
Switch 1/7 (OFF)
DIRECT Mode On
Switch 1/7 (ON)
Passive Mode Off
Token passing to
a HIMA OPC server
Switch 1/8 (ON)
Passive Mode On
No token passing to an
HIMA OPC server
Switch 1/8 (OFF)
If "DIRECT Mode Off"
switch 1/7 is activated (ON), the
F 8627X's settings remain
"Passive Mode On".
Deactivate the Passive
Mode in the HIMA OPC
server.
Activate the Passive Mode
in the HIMA OPC server.
Activate the Passive Mode in
the HIMA OPC server.
Number of HIMA OPC
servers fixed to 4
Number of HIMA OPC
servers fixed to 4
Up to 14 OPC servers can be
used
Switch S2/6-8
Monitoring Time
for HIMA OPC server:
fixed to 16 ms
Monitoring Time
for HIMA OPC server:
fixed to 16 ms
Monitoring Time
for HIMA OPC server:
fixed to 6 seconds
The F 8625 / F 8627(X)
communicates with an
OPC server via BUSCOM
variables.
The F 8625 / F 8627(X)
communicates with an
OPC server via BUSCOM
variables.
The F 8627(X) communicates
with an OPC server via BUS-
COM variables.
For communicating with a
HIMA OPC server without
Passive Mode, HIPRO-S
variables must be sent from
each PES to all other PES
(one data direction is suffi-
cient) to ensure token pass-
ing.
HIPRO-S dummyies may
have to be configured.
HIPRO-S variables
must
not
be defined when com-
municating with a HIMA
OPC server in passive
mode (otherwise OPC with-
out passive mode).
F 8625: from V. 1.13
F 8627(X): from V. 2.x
No restrictions/specifica-
tions for HIPRO-S vari-
ables.
F 8625: from V. 1.17
F 8627 / F 8627X:
from version 3.x on
No restrictions/specifications for
HIPRO-S variables.
Hub/Switch Switch Switch
HSR cable required for
redundancy
HSR cable required for
redundancy
HSR cable is required for
ELOP II TCP and MODBUS
TCP (Port 502)
Half/Full-Duplex Full-Duplex Full-Duplex
The simultaneous use of both an F 8621A coprocessor module for
safety-related communication and an F 8627X communication module
for Ethernet communication is not allowed.
