F 8627X (0650)
381
Via MODBUS TCP port 8896, the F 8627X supports the following function codes:
The HIMA Modbus slave supplies identification data to the master and supports the following
Object-Ids:
Basic:
0x00 VendorName "HIMA Paul Hildebrandt GmbH + Co KG"
0x01 ProductCode "<Serial Number>"
0x02 MajorMinorRevision "<CU-OS Key 0x23ad CRC 0x-------- / COM Vx.y CRC>"
Regular:
0x03 VendorUrl "http://www.hima.com"
0x04 ProductName "HIQuad"
0x05 ModelName "<RessourceTyp>" z.B. "F 8627X"
0x06 UserApplicationName "<Buchst00>" resource name from ELOP projekt
Extended:
0x80 CPU OS version/CRC "< CU-OS Key 0x23ad CRC 0x-------->"
0x81 CPU OSL version/CRC deliver the error code 2 (Invalid Data)
0x82 CPU BL version/CRC deliver the error code 2 (Invalid Data)
0x83 COM OS version/CRC "<Vx.y / 0x234adcef>"
0x84 COM OSL version/CRC deliver the error code 2 (Invalid Data)
0x85 COM BL version/CRC deliver the error code 2 (Invalid Data)
0x86 Configuration-CRC "<Data-version 0x13ac / Area-version 0x13ac / Code-version
0x13ac / Run-version 0x13ac>"
Function Code Type Description
Read Coils 01 BOOL Reads several variables (BOOL) from
the slave’s import or export area
(same range as code 02).
Read discrete Inputs 02 BOOL Reads several variables (BOOL) from
the slave's export area.
Read Holding Registers 03 WORD Reads several variables of any type
from the slave's import or export area
(same range as code 04).
Read Input Registers 04 WORD Reads several variables of any type
from the slave's export area.
Write Single Coil 05 BOOL Writes one single variable (BOOL) in
the slave's import area.
Write Single Register 06 WORD Writes one single variable (WORD) in
the slave's import area.
Write Multiple Coils 15 BOOL Writes several variables (BOOL) in
the slave's import area.
Write Multiple Registers 16 WORD Writes several variables of any type in
the slave's import area.
Read/Write Multiple Registers 23 WORD Writes and reads several variables of
any type in and from the slave's
import area.
Read Device Identification 43
x
1)
1) Note about the Modbus Function: Read Device Identification (43)
Transmits the slave's identification
data to the master.
