Mechanical design and dimensions of Terminal Module H 7016
Figure 2: Mechanical design and dimensions of Terminal Module H 7016
Application: Wiring of H 7015 with H 7016
For fast and efficient wiring (plug and play) between a PLC cabinet and a marshalling cabinet,
the Terminal Modules H 7015, H 7016 and the cable BV 7201 are required.
Figure 3: Wiring of H 7015 with H 7016
Depth 105 mm with Vario-plug ELCO 8016
Mounting on 35 mm DIN-rail
Installation orientation horizontally or vertically
Installation clearance min. 25 mm to next Terminal Module H 7016
Terminal Module H 7015
E Vario-plug ELCO 8016
A,B,C Phoenix Headers
D Terminal block
4x supply contacts, coupled
6x floating contacts
2x contacts Y, for shield
