Time
RM Web L3E
Release
6.0
07/2010
3.1
SNTP configuration
71
Parameter Meaning Possible
Values
Default
Setting
Server status Switches the SNTP server on and off. On, Off On
Anycast destination
address
IP address, to which the SNTP server of the
device sends the SNTP packets (see
table 13).
Valid IPv4
address
0.0.0.0
VLAN ID VLANs to which the device periodically
sends SNTP packets.
1
Anycast send interval Time interval at which the device sends
SNTP packets.
1 - 3,600 120
Disable Server at
local time source
Enables/disables the SNTP server function if
the status of the time source is local (see
Time dialog).
On, Off Off
Table 12: Configuration SNTP Server
IP destination address Send SNTP packet to
0.0.0.0 Nobody
Unicast address (0.0.0.1 - 223.255.255.254) Unicast address
Multicast address (224.0.0.0 - 239.255.255.254),
especially 224.0.1.1 (NTP address)
Multicast address
255.255.255.255 Broadcast address
Table 13: Destination address classes for SNTP packets
