Honeywell 5704 User Manual

4-55
CHAPTER 4 - INSTALLATION INSTRUCTIONS
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
16-Way AC to DC Power Supply Unit (100W)
16-Way AC to DC Power Supply Unit (150W)
Front View
Top View
Rear View
50W Switched Mode AC to DC
Power Supply Module
50W Switched Mode AC to DC
Power Supply Module
50W Switched Mode AC to DC
Power Supply Module
Earth
Stud
24V 50W DC
Output
Input AC
Supply Voltage
Earth
Stud
24V 100W DC
Output
Input AC
Supply Voltage
Front View
Top View
Rear View
50W Switched Mode AC to DC
Power Supply Module
50W Switched Mode AC to DC
Power Supply Module
Input AC
Supply Voltage
24V 100W DC
Output
Earth
Stud
