CHAPTER 5 - COMMISSIONING AND
MAINTENANCE INSTRUCTIONS
This provides a warning that the sensor is
detecting a level of gas exceeding the set
operating range of the channel.
IMPORTANT
If congured for latching, the display
and analogue output may not indicate
the true gas concentration when
the measuring range is exceeded.
The reset of a latched signal overrange
warning condition should only be carried
out after checking that the sensor is in
clean (non target gas) air.
Error Error Code Meaning Software Card Fault Latch
Code Version Status Signal
79 Uncalibrated
The uncalibrated message is displayed for
new channel cards that have never been
calibrated.
The channel card should be calibrated and
its operation checked.
78 Calibration Overdue
The calibration overdue message is
displayed when the pre-configured
calibration interval has expired.
This is a warning message that the sensor
is due for calibration. Once the calibration
has been completed the message will
clear.
If required, this function can be disabled
using the Engineering Interface Software
congurationprogram.
5.4 Calibration Errors
Error Error Code Meaning Software Card Fault Latch
Code Version Status Signal
All Non No No
Active
All Active No No
