Honeywell 5704 User Manual

3-2
CHAPTER 3 CONTROLS AND FACILITIES
MAN0448_Issue 13_2010 5704 Control System
005704-M-5001 A03249
CONTENTS
Section Page
1. Introduction 3-3
2. Four Channel Control Card 3-8
2.1 General 3-8
2.2 Liquid Crystal Display 3-8
2.3 Status LEDs 3-11
2.4 Reset/Select Push-button 3-14
2.5 Extraction Slot 3-15
2.6 Display Label and Cover 3-15
3. Engineering Card 3-17
3.1 General 3-17
3.2 LED Indicators 3-17
3.3 Engineering Push-buttons 3-18
3.4 Engineering Serial Port 3-21
