Honeywell 5704

8-4
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
CHAPTER 8 - SPECIFICATION
4. POWER SUPPLIES
PowerConsumption: Dependentuponconguration.
(System) See Chapter 4, Section 5.
External DC Power Supply: 18V to 32V to DC Input Card.
ExternalACPowerSupply: 85Vto264Vat47Hzto440Hz.
(Using optional AC to DC PSU).
5. INDIVIDUAL MODULE PARAMETERS
5.1 Quad Relay Interface Card (05704-A-0121)
Dimensions: Height 132mm.
Width 25mm.
Depth 119mm.
Weight: 230g.
Power: 1.7W (maximum) 1W (typical).
Relays: 4 x SPCO.
Relay Operation: Selectable.
Latching/Non-Latching.
Energised/De-Energised.
Relay Contact Rating: 5A at 110V/250V ac (non inductive).
5A at 32V dc (non- inductive).
Field Terminals: 2.5mm
2
(14 AWG).
5.2 Relay Interface Assembly (05704-A-0131)
ConsistsofaExpansionRelayCardttedtoaQuadRelayInterface
Card.
Dimensions: Height 132mm.
Width 52mm.
Depth 122mm.
Weight: 500g.
Power: 6.5W (maximum) 3.5W (typical).
Relays: 12 x SPCO.
4 x SPST.
