Honeywell 5704

2-25
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
CHAPTER 2 - SYSTEM DESCRIPTION
8.6 50W Sub-Unit Layout
The50WSub-unitisttedwithasingle50WSwitchedModeACtoDC
Power Supply Module as shown below:
Thistypeofunitisidentiedontheidenticationlabelasfollows:
8.7 100W Sub-Unit Layout
The 100W Sub-unit is a 50W Sub-unit with an additional 50W
SwitchedModeACtoDCPowerSupplyModuletted asshown
below:
Thistypeofunitisidentiedontheidenticationlabelasfollows:
Top View
(with cover
removed)
50W Switched Mode
AC to DC Power
Supply Module
50W Switched Mode
AC to DC Power
Supply Module
Additional 50W
Switched Mode AC
to DC Power Supply
Module
Top View
(with cover
removed)
POWER SUPPLY UNIT 05700-A-0405 Iss. 2
INPUT = 85 - 264V AC OUTPUT = 24V DC
47 - 440Hz POWER = 50W
OR 110 - 340V DC = 100W
Indicates
50W Unit
POWER SUPPLY UNIT 05700-A-0405 Iss. 2
INPUT = 85 - 264V AC OUTPUT = 24V DC
47 - 440Hz POWER = 50W
OR 110 - 340V DC = 100W
Indicates
100W Unit
