CHAPTER 8 - SPECIFICATION
Relay Operation: Selectable.
Latching/Non-Latching.
Energised/De-Energised.
Relay Contact Rating: 5A at 110V/250V ac (non inductive).
5A at 32V dc (non- inductive).
Field Terminals: 2.5mm
2
(14 AWG).
5.3 Four Channel Control Card - General
Four-Part Liquid Display:
Analogue Display: 25 segment.
Digital Display: Four character.
Message Display: Four character.
Icon Section: Power On/Card Select.
LED Indicators: CHL 1, CHL 2, CHL 3, CHL 4 and ATTN.
CHL Indicators: Two colour amber / red providing warnings
of:
  A1Alarm: 1quickredashpersecond.
  A2Alarm: 2quickredashespersecond.
  A3Alarm: 3quickredashespersecond.
  STEL,LTEL Slowredash,1secondon1secondoff.
Fault: Flashing amber.
Inhibit: Steady amber.
ATTN Indicator:
Hardware
  orSoftwareFault: Slowashingamber.
Update Alarm
  Condition: Fastashingamber.
Alarm Test: Steady amber.
Push-Button: Alarm Reset/Card Select.
Initial accuracy: ±1%.
Alarm Setting Point
Resolution: In 1% fsd steps.
