Honeywell 5704 User Manual

8-12
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
CHAPTER 8 - SPECIFICATION
8. POWER SUPPLY UNITS
Mounting: Universal 19'' and half 19'' mounting.
SupplyVoltage: 85Vto264Vac47Hzto440Hz.
110V to 340V dc.
(For information on dc input contact
Honeywell Analytics).
Inrush Current: Typically 30A at 230V input on full load
per 50W Module.
Leakage Current: 0.75mA maximum per 50W Module.
Overload Protection: Operates at more than 105% of rated
full load and recovers automatically.
Safety Approvals: 50W Module approved to UL1950,
IEC950, CSA 22.2 No 234.
Output Voltage: 24V ± 10% dc.
OutputCongurations:
Half 19'' Rack: 50W or 100W.
Full 19'' Rack: 50W, 100W, 150W or 200W.
Earthing Point: M5 stud.
Weight:
Half 19'' Rack 50W: 900g.
Full 19'' Rack 50W: 960g.
50W Module: 230g.
Sub Unit: 815g.
