Display/Alarm Point:
Linearity: ±2% fsd.
Repeatability: ±2% fsd.
Remote Facilities: Inhibit/Alarm Reset.
Remote Inhibit / Reset Inputs
Active For Inputs: More than 2V.
Maximum Input Voltage: 32V.
Maximum Input Current: 5mA.
DC Supply: 18V to 32V dc.
Electronic Drift: Less than ±3% / 6 months.
Dimensions: Height: 132mm.
Width: 25mm.
Depth: 172mm.
Weight: 170g.
5.4 Four Channel Control Card - Catalytic
Power Consumption: 12.8W (maximum at 200mA sensor
current).
8.5W (typical).
Drive: Constant Current.
Initial Accuracy: ±1%.
CurrentAdjustment: Electronic in 1mA stepsfrom 90 to
315mA.
Maximum Drive Voltage: 10V.
Protection: Protected against short circuit and
open circuit.
Maximum Line Resistance: 40 ohms (including sensor) at
200mA.
Full Scale Signal Range: 15mV to 300mV.
Bridge Imbalance Default Limits: ±100mV from centre at 2V bridge
voltage.
Adjustment: Electronic adjustment of bridge
balance and signal gain.
