CHAPTER 8 - SPECIFICATION
5.7 Engineering Card
LEDs: Power On ( - Green LED).
Unlocked ( - Red LED).
Push-Button:
Operating: Up (
) and Down ( ).
  Reject(
) and Accept ( ).
Print (Up and Down together).
Functions: Bead mA Alarms
Zero Signal
Span 1st Span
Inhibit Clock
Power Consumption: 1.5W (typical). See rack details.
DC Supply: 18V to 32V dc.
Dimensions: Height: 132mm.
Width: 25mm.
Depth: 170mm.
Weight: 152g.
5.8 DC Input Card
DC Supply: 18V to 32V dc.
Dimensions: Height: 112mm.
Width: 25mm.
Depth: 102mm.
Weight: 129g.
Fuse Rating: 10A Anti-surge. 11/4 x 1/4 inches.
FieldTerminals: 2.5mm˝(14AWG).
