Honeywell 5704

7-2
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
CHAPTER 7 - ENGINEER'S OPERATING
INSTRUCTIONS
CONTENTS
Section Page
1. General 7-3
2. Engineering Operating Routines 7-3
3. Unlocking the Engineering Card 7-4
4. Selected Card Operations 7-4
5. Channel Inhibit 7-5
6. AlarmCongurationandRelayTest 7-6
7. CatalyticSensorBridgeCurrentAdjustment 7-9
8. Zero Signal Calibration 7-10
9. Span Signal Calibration 7-11
10. First Time Span Signal Calibration 7-13
11. Sensor Signal Monitoring 7-13
12. Setting the Clock/Calendar 7-14
13. Maintenance Operating Routines 7-15
