CHAPTER 2 - SYSTEM DESCRIPTION
5.3 Relay Interface Assembly (Part Number 05704-A-0131)
5.3.1 General
ThefollowingdiagramsshowtheExpansionRelayCardttedtothe
Quad Interface Relay Card to form a Relay Interface Assembly:
Front Access
Top View
Expansion
Relay
Card
Quad Relay
Interface
Card
Expansion
Relay
Card
Quad Relay
Interface
Card
Expansion
Relay
Card
Quad Relay
Interface
Card
Rear Access
Front View
Front Access
Front View
1. For details of the Quad Interface Card, see Section 5.2.
2. For details of the Expansion Relay Card, see Sections 5.4.
