CHAPTER 2 - SYSTEM DESCRIPTION
8.4 8-Way AC to DC Power Supply Unit Layout
8.5 16-Way AC to DC Power Supply Unit Layout
Front View
Top View
Rear View
24V dc Output Voltage.
50W per Fitted Module
Input ac
Supply Voltage
Input ac
Supply Voltage
24V dc Output Voltage.
50W per Fitted Module
Input ac
Supply Voltage
24V dc Output Voltage.
50W per Fitted Module
Optional Sub Unit
