Honeywell 5704 User Manual

6-2
MAN0448_Issue 13_01-2010 5704 Control System
005704-M-5001 A03249
CHAPTER 6 - OPERATING INSTRUCTIONS
CONTENTS
Section Page
1. GENERAL 6-3
2. USER OPERATING ROUTINES 6-3
3. CONTROL CARD 6-4
3.1 Reset 6-4
3.2 Extended Reset 6-4
3.3 Channel Reset - TWA Calculations 6-5
3.4 Card and Channel Select 6-5
3.5 Deselect 6-6
4. ENGINEERING CARD 6-6
4.1 General 6-6
4.2 Timeout 6-7
4.3 Bargraph Display 6-7
4.4 Catalytic Sensor Bridge Current 6-7
4.5 View Alarm Level Settings 6-7
4.6 Sensor Signal Monitoring 6-8
4.7 View Clock/Calendar 6-9
4.8 Maintenance Record Printout 6-10
